SENZ NOVA Compact Angled Shape HeatPro intelClean Cooker Hood



Model No: SZ-CH2898DC

Key Features

1. Latest Hybrid (Chimney + Angled) Design – a perfect fusion of traditional chimney structure and modern angled hood, blending timeless elegance with sleek innovation
2. 2000 m3/h Suction Power + Turbo Boost – instantly removes smoke, perfect for heavy cooker
3. Motion Sensor Technology – operate without touching, just wave your hand to activate the hood or switch speeds easily, even with oily hands!
4. Ultra-Quiet Operation – as low as 45dB, enjoy conversation in the kitchen without disruption
5. Heat Auto Cleaning Function – uses high-heat dissolves grease automatically, no dismantling, no manual cleaning, ensures long-lasting performance

Additional Practical Features

• BLDC Motor – more energy saving
• 5x Larger Metal Oil Cup – reduces cleaning frequency
• LED lighting – bright and even illumination, glare-free
• Retractable Panel Design – panel slides upward during use for better smoke capture, retracts when off for a sleek, space-saving look
• Removable Magnetic Metal Filter – easily attaches and detaches for quick cleaning

Installation Accessories Included

• 1 pcs Washable Metal Filter
• Chimney Cover
  – 1st Glass Chimney
  – 2nd Metal Chimney
• Stainless Steel Wall Cap
• 3 meters Aluminum Hose (hose dimension: 180mm (7”))
• Ducting/Coring Size: 150mm = 6 inches (includes connector to adapt from 180mm to 150mm for easy installation)

Recommended Installation Height

• From bottom of hood to your counter top
  – For Electric Hob / Gas Hob: 600mm ~ 700mm

Optional Accessories

• Charcoal Filter

Plug Used

USER MANUAL
